Heavy Duty Hybrid Vehicle Gate

Frames are made up of 60 x 40 x 2.0mm Hot Rolled Square Hollow Section.
Posts are made up of 100 x 100 x 4.0mm Hot Rolled Square Hollow Section.

The vehicle gate posts sit 600mm in-ground, subsequently they are 600mm longer than the size of the vehicle gate e.g. a 2.4 meter high vehicle gate will come with 3.0 meter vehicle gate posts.
The fill is made up of steel cladding on the bottom half and mesh of the top half. These are welded to the vehicle gate frame.
The posts and vehicle gate frame are connected using an eyebolt system.

All of our heavy duty construction site vehicle gates come with a slide bolt allowing you to secure them shut and maximise site security.

Size: Our construction site hybrid vehicle gates are available in a range of sizes including 2.0 & 2.4 meter heights and 4, 5 & 6 meter widths.

Finish: Vehicle gates are normally painted (one-side). However we can have these painted or powder coated to suit your requirements, so if you do not see the option you would like please get in touch with a member of our team.
